The MAXWELL VW 1500 Series is a powerful and reliable vertical windlass (capstan) model for boats and yachts. It features a 1200W motor that can operate compatibly with both 12V and 24V electrical systems. It also offers a hydraulic drive option.
The product is suitable for use with stud link chains ranging from 6 to 10 mm in thickness. It provides a maximum pulling force of 850 kg and a static holding force of 1500 kg. The normal operating speed is 18 meters per minute.
| Maximum Pulling Force | 850 kg |
| Static Holding Force | 1500 kg |
| Stud Link Chain | 6-10 mm |
| Operating Speed | 18 m/min |
| Power Source (Voltage) | 12V / 24V |
| Motor Power | 1200W |
| Hydraulic Pressure | 138 bar |
| Hydraulic Flow | 20 L/min |
| Net Weight (Electric) | 22 kg |
| Net Weight (Hydraulic) | 15 kg |
Stock Code
:
2174854962
MAXWELL Maxwell VW 1500 Series 1200W 12/24V 6-10 mm Drum Hydraulic Vertical Windlass
The MAXWELL VW 1500 Series is a vertical windlass with a 1200W motor power, offering a choice of 12/24V electric or hydraulic drive, suitable for 6-10 mm link chain. It has a maximum pull of 850 kg and a static holding power of 1500 kg.
Price
₺222.775,49
Bank Transfer / EFT
%6 bank transfer / eft discount
₺209.408,96
Installment payment is only available for Turkish Lira.
Free Shipping
Technical Details
