The MAXWELL VW 3500 Series is a powerful and reliable vertical windlass model for boats and yachts. It operates with a 1200W motor power and a 24V electrical system, while also offering a hydraulic drive option. It is compatible with 8-13 mm stud link chains and functions as a capstan.
| Maximum Pulling Power | 1590 kg |
| Static Holding Power | 2200 kg |
| Normal Working Speed | 10 m/min |
| Power Source (Voltage) | 12V / 24V |
| Motor Power | 1200W |
| Net Weight (Electric) | 48 kg |
| Hydraulic Pressure | 138 bar |
| Hydraulic Flow | 42 L/min |
| Net Weight (Hydraulic) | 40 kg |
Stock Code
:
2332109070
MAXWELL Maxwell VW 3500 Series 1200W 24V 8-13 mm Drum Vertical Windlass
The MAXWELL VW 3500 Series is a vertical windlass with a 1200W motor, offering a choice of 24V electric or hydraulic drive, designed for 8-13 mm chain. The maximum pulling force is 1590 kg.
Price
₺237.023,05
Bank Transfer / EFT
%6 bank transfer / eft discount
₺222.801,67
Installment payment is only available for Turkish Lira.
Free Shipping
